RF Power Amplifiers

RF power amplifiers trusted from ground to space. Our industry-leading portfolio includes GaN-based SSPA products and is customizable to support your mission-critical application.

Explore High-Power RF Amplifiers

+ High-Power CW Amplifiers
Model Number Freq Start (GHz) Freq Stop (GHz) Psat (dBm) Psat (W) Gain (dB) min PAE typ. Vd (VDC) Id (A) Datasheet
DM-HPMB-10-103 0.1 6 39 10 55 20% 28 2.2

View

DM-HPMB-25-102 0.5 6 25 20 50 20% 50 2.3

View

DM-HPLS-25-101 1 3 43 25 50 30% 45 2.5

View

DM-HPLS-100-101 1 3 49 100 50 25% 45 10

View

DM-HPLS-50-101 1 3 46 50 50 30% 45 4

View

DM-HPL-10-102 1.625 1.85 40 15 30 35% 28 1.7

View

DM-HPSC-150-101 2 6 51.5 150 60 25% 28 25

View

DM-HPSC-25-101 2 6 43 25 45 30% 28 3

View

DM-HPSC-50-101 2 6 46 50 50 30% 28 6

View

DM-HPSC-80-101 2 6 48 80 50 25% 28 12

View

AML218P4012 2 18 37 6 35 13% 32 1.5

View

DM-HPMB-10-101 2 18 38 10 45 15% 24 2.5

View

AML218P4011 2 18 39 10 40 12% 32 2.8

View

DM-HPMB-5-101 2 18 36 5 45 15% 32 1.5

View

AML218P4013 2 18 42 20 38 12% 32 4.9

View

DM-HPS-10-101 2.2 2.5 40 15 14 35% 28 1.7

View

DM-HPS-35-101 2.2 2.5 45.5 40 20 35% 28 3.6

View

MSC56P4544 5 6 42 15 45 30% 30 2.8

View

MSC56P4042 5 6 40 10 40 30% 30 1.8

View

MSC56P5050 5 6 48 63 50 30% 30 11

View

L0505-50 5.3 5.9 50 100 50 15% 15 40

View

MSC58P4549 5.5 8 49 80 45 20% 28 12

View

DM-HPC-60-101 5.5 8.5 46 50 50 25% 28 6.5

View

DM-HPC-30-101 5.5 8.5 44 35 50 25% 28 3.5

View

AML59P4512 5.5 9 44 25 45 25% 28 4

View

DM-HPMB-40-101 6 18 42 30 50 15% 28 8

View

L0618-43 6 18 43 20 41.5 7% 12 25

View

L0618-40 6 18 40 10 38.5 7% 12 12

View

AML618P4014 6 18 40 10 40 12% 32 2.8

View

DM-HPMB-25-101 6 18 40 15 50 15% 28 4.5

View

L0618-46 6 18 46 40 40 7% 12 12

View

AML618P4015 6 18 42 15 40 12% 32 4.9

View

AML811P5012 7.8 11 45.5 35 50 23% 28 5.5

View

AML811P5013 7.8 11 48 63 50 25% 28 11.5

View

DM-HPX-50-102 8 11 46 40 50 30% 28 6

View

DM-HPX-25-101 8 11 43 25 45 30% 28 3.5

View

DM-HPX-30-101 8 11 44 30 45 22% 28 5.5

View

L0812-46 8 12 46 40 45 12% 12 28

View

L0809-45 8.5 9.6 45.5 35 50 10% 15 22

View

L0910-45 9 10.5 45 30 45 10% 15 24

View

DM-HPX-100-105 9.75 10.25 49.5 100 50 30% 28 17

View

DM-HPKU-40-105 13.75 14.5 47 50 45 25% 24 10

View

DM-HPKU-25-105 13.75 14.5 44 25 45 20% 24 6

View

AML1314P4511 13.75 14.5 42 15 45 20% 30 2.3

View

AML1314P4512 13.75 14.5 44.5 28 45 19% 30 4.6

View

AML1416P4511 14 16 41.5 14 45 20% 35 3.2

View

AML1416P4512 14 16 44 25 45 18% 35 6.2

View

DM-HPKU-40-104 14.4 15.35 44 30 53 15% 28 6

View

DM-HPKU-20-101 14.4 15.5 41.5 15 45 15% 28 3.5

View

DM-HPKU-40-101 14.5 15.5 44 30 45 15% 28 6.5

View

DM-HPKU-30-102 14.85 15.35 41 30 45 20% 28 3.5

View

L1826-36 18 26 36 4 38 5% 12 8

View

L1840-27 18 40 26.5 0.45 30 3% 12 4

View

L2426-40 24 26 39.5 9 40 5% 12 16

View

L2632-37 26 32 37 5 38 5% 12 10

View

L2640-32 26 40 32 1.6 35 5% 12 5

View

MSC2930P1741 29 30 40 10 15 23% 28 2.2

View

DM-HPKA-10-102 29 31 40 10 50 15% 20 3.6

View

DM-HPKA-20-102 29 31 42 20 50 15% 20 6

View

MSC2931P3540 29.5 31 40 10 35 15% 5 19

View

L3236-38 32 36 38 6.3 40 5% 12 17

View

L3434-40 34 34.5 40 10 45 5% 12 17

View

L3640-37 36 40 37.5 5.6 40 5% 12 17

View

+ High-Power Pulsed Amplifiers
Model Number Freq Start (GHz) Freq Stop (GHz) Psat (dBm) Psat (W) Gain (dB) min PAE typ. Vd (VDC) Datasheet
DM-HPS-1K-103 3.1 3.5 58.5 800 60 40% 50

View

DM-HPX-140-101 7.8 9.6 51 140 50 30% 40

View

DM-HPL-1K-102 1.2 1.4 61 1600 60 40% 50

View

DM-HPS-800-102 2.9 3.1 58.5 800 60 40% 32

View

DM-HPX-250-102 9.4 10.1 53 250 50 30% 50

View

DM-HPS-1K-104 3.1 3.5 61 1300 60 35% 50

View

DM-HPC-50-105 5.2 5.9 46 50 50 35% 32

View

DM-HPL-1K-101 1.2 1.4 59 1000 60 40% 50

View

DM-HPS-1K-103 2.9 3.1 61.5 1500 60 35% 50

View

DM-HPS-1K-105 2.7 2.9 60.5 1250 60 35% 32

View

DM-HPX-1K-101 9.4 10.1 61.5 1500 60 25% 50
DM-HPS-1K-102 2.9 3.1 61 1300 60 35% 32

View

DM-HPX-800-101 9.4 10.1 59 900 60 30% 50

View

DM-HPX-400-102 9.4 10.1 56 450 50 30% 50

View

MSC010P4355 1.02 1.04 66 3700 60 42% 65

View

+ High-Power Rack Mount Amplifiers
Model Number Freq Start (GHz) Freq Stop (GHz) Psat (dBm) Psat (W) P1dB (dBm) Pac (kW) Height (in) Datasheet
C0812-46 8 12 46 40 44 0.4 5.25

View

C0618-43 6 18 43 41.5 41.5 0.3 5.25

View

C059064-55 5.9 6.4 55 300 52 3 10.25

View

C033036-51 3.3 3.6 51 125 50 1 8.75

View

C090105-50 9 10.5 50 100 49 1 8.75

View

C0618-46 6 18 46 40 44.5 0.75 8.75

View
