20 MHz to 6 GHz High P1dB Gain Block
AM1193 is a high dynamic range cascadable gain block covering the 20 MHz to 6.0 GHz frequency range. The device supports up to +30dBm P1dB, high second and third order intercept performance, and low noise figure while also providing excellent gain stability over the operating temperature range. Includes internal 50Ω matching and is packaged in a 4mm QFN or a shielded module
.02 - 6
Frequency (GhZ)
15
Gain (dB)
2.0
NF (dB)
40
OIP3 (dBm)
Products formerly Atlanta Microwave
Purpose-Built MMIC Components
Enable Portable Platforms
Leverage the latest in solid-state GaAs technology with off-the-shelf, broadband MMIC devices that operate at high frequency to enable portable and low-power platforms.
