Medium-Power, Broadband Amplifiers

Our family of distributed amplifiers utilize advanced broadband design techniques to achieve solid performance in gain, flatness, noise figure and output power over a wide frequency range. The experienced design team has the know-how and tools available to take any standard product and customize it for your specific application.

Scroll Arrow

Medium Power, Broadband Amplifiers

Model Number Sortable column, activate to sort column ascending Freq Start (GHz) Sortable column, activate to sort column ascending Freq Stop (GHz) Sortable column, activate to sort column ascending Gain (dB) min Sortable column, activate to sort column ascending Flatness (±dB) max Sortable column, activate to sort column ascending NF (dB) max Sortable column, activate to sort column ascending P1dB (dBm) min Sortable column, activate to sort column ascending OIP3 (dBm) nom Sortable column, activate to sort column ascending VSWR (In/Out) nom Sortable column, activate to sort column ascending Voltage (V), Current (mA) Sortable column, activate to sort column ascending Datasheet
AML0126P3002 0.1 26.5 30 3 6.0* 22 30 2.0:1 12V, 600mA PDF
DM-MPMB-36-101 2 18 37 1.5 3.5 22 30 2.0:1 11V, 500mA PDF
AML0118P3201 0.1 18 32 3 3.5* 26* 32* 2.5:1 15V, 750mA PDF
DM-MPMB-20-101 0.5 18 20 1.75 6.5 23 31 2.0:1 11V, 450mA PDF
DM-MPMB-30-102 0.5 2 31 1.5 3.6 26 36 2.0:1 11V, 400mA PDF
DM-MPMB-18-101 2 18 18 1.25 5.6 24 32 2.0:1 11V, 500mA PDF
DM-MPMB-22-102 0.5 2 22 1 3.6 26 36 2.1:1 11V, 300mA PDF
DM-MPSC-18-102 2 6.5 16 1 5.6 24 34 1.8:1 11V, 475mA PDF
AML118P2703 1 18 27 2 4 27 34 2.0:1 15V, 525mA PDF
AML618P4202 6 18 42 2.5 3 35 42 1.8:1 12V, 2200mA PDF
DM-MPMB-30-101 6 18 30 1.25 5 19 22 2.0:1 11V, 350mA PDF
DM-MPMB-25-102 6 18 25 2 3 20 30 2.0:1 11V, 450mA PDF
AML120P3201 1 20 32 3.5 5 27 32 2.0:1 15V, 1500mA PDF
AML1840P2802 18 40 35 3 6.5 22 28 2.0:1 12V, 800mA PDF
