MFCC SBC INTEL XMC Module with BuiltSAFE

MFCC-8580 and MFCC-8581

Single Board Computer for advanced aerospace systems

Mercury’s ITAR-free rugged and reliable Multi-Function Computing Core (MFCC) modules are designed for advanced aerospace systems. They deliver fast processing and high quality video, work seamlessly with modern modular hardware, and are designed to meet important safety standards. Built for long term use and fully exportable, they are a dependable choice for global programs.

These ruggedized, high-performance Single Board Computers feature an Intel Core-i7 processor with an embedded GPU and compatible with SOSA™-aligned VITA 65 OpenVPX carrier boards. This offers unparalleled real-time processing and video capabilities for aerospace applications, ensuring reliability, safety certification up to DAL-B or DAL-D, and long-term lifecycle support without export restrictions.

DOWNLOAD MFCC-8580 DATASHEET

DOWNLOAD MFCC-8581 DATASHEET

MFCC SBC XMC Single Board Computer with BuiltSAFE.png

IoTsa_k_wht_280x64 (1).png

Ensuring applications run reliably on embedded software

The MFCC-8580 is the first member of the INTEL Core-i7 11th Generation BuiltSAFE product line, designed to support advanced video and high-resolution graphics processing. The MFCC-8581 is for high-performance embedded computing applications that are Safety Critical and support DO-254/DO-178C certification up to DAL-B.

Embedded Computing

Optimized for real-time processing in aerospace applications

Embedded GPU

Supports advanced video features and high-resolution graphics processing

Ruggedized Design

Built to withstand extreme temperatures and other harsh environmental conditions

XMC Form Factor

Compatible with SOSA™-aligned VITA 65 OpenVPX carrier boards for modular and scalable system integration

Safety-Certifiable

Suitable for use in applications up to Design Assurance Level B (DAL-B) or D (DAL-D) per DO-178C/DO-254 standards

MFCC-8580 MFCC-8581

MFCC-8580

The MFCC-8580 board is architected using Mercury’s proven BuiltSAFE Commercial-Off-The-Shelf (COTS) elements and artifacts to deliver flawless performance and ease of systems integration.

Key Features

High-Performance Embedded Computing
Ruggedized Design for harsh environmental conditions
Designed with BuiltSAFE TM technologies
ITAR-Free
Compatible with SOSA™-aligned VITA 65 OpenVPX carrier boards
Safety certifiable with Design Assurance Levels B and D (DAL) per DO-178C/DO-254 standards

Processing and Video

Intel Core-I7 1185GRE 4-cores @4.4GHz turbo freq (UP3-class)
Intel Iris Xe GPU @1.35GHz – TDP 28W
Board management Controller (BMC)

Memory

2x DDR4 x16 channels (16GB each) up to 3200MT/s supporting In Band ECC
64GB SSD (SLC technology)

XMC interfaces

1x PCIe gen4 x4 (CPU)
1x PCIe gen3 x4 (PCH)
2x PCIe gen3 x1 OR 2x SATA 3.0 (PCH) – a combination 1x PCIe/ 1x SATA may be supported
1x USB 2/3 (CPU)
1x Display Port MST out (CPU) up to HBR2.
2x 10GBASE-KR (Ethernet controller E810) OR Video pipe input (4 lanes)
2x 1000BASE-KX (Ethernet controller I350)
1x SPI with 2 CS / 1x SMBUS / 1x I2C / 2x UART (PCH)

Security Features

Trusted Platform Module Rev 2.0
SE051 security IC (root of trust)
I2C authentication

Rugged and Low Power

Operating Temp: 0°C to 55°C or -40°C to 85°C options. Customizable.
DO-160G, MIL-STD-810G, MIL-STD-1686C, MIL-STD-202H option

Power Consumption

Minimum: 29W
Typical: 32W
Maximum: 48W

SW support

Certifiable Video libraries (CoreAVI)

Compliance

XMC 2.0 (VITA-61)
Compatible with SOSA™-aligned VITA 65 OpenVPX carrier boards
DO-254 hardware up to DAL-D
DO-178C board management features and processor board support packages up to DAL-D
Design and quality assurance
Full Configuration control
Pro-active Obsolescence Management

Export Control Classification (ECN)

CH ECN: N/A
Tariff Nr: 8471.5000
LIC: No License Required (NLR)
Origin: Switzerland
Optimized BIOS/UEFI
Mercury Yocto Linux distribution for embedded application

Third- Party Compatibility

Various RTOS, (PIkeOS, Integrity, LynxOS, VxWorks)

BuiltSAFE™ Proven Elements

MFCC-8581

The MFCC-8581 board is architected using Mercury's proven BuiltSAFE Commercial-Off-The-Shelf (COTS) elements and artifacts to deliver flawless performance and ease of systems integration.
