AM2152
DC-20 GHz, 2dB Slope, 1.3x2mm DFN
Function:
Fixed Slope Equalizer
Package:
1.3 x 2 mm DFN ECCN:
EAR99 AM2152 is a fixed slope equalizer with 2dB of positive slope from DC to 20 GHz.
Mercury offers fixed equalizers of 2dB, 4dB, 6dB, and 8dB slopes to 20 GHz and fixed attenuators up to 5dB to provide flexibility in component selection. The AM2152 is packaged in a small 1.3mm x 2mm DFN package and is footprint compatible with the rest of Mercury’s fixed passive equalizer and attenuator offerings.
0
Frequency (GHz) Low
20
Frequency (GHz) High
2
Slope (dB)
