RFM3113

SOSA-aligned microwave dual upconverter

  • slide

Microwave RF upconverter supporting secure, SWaP-focused applications


The RFM3113, formerly the RFM3103s, is a SOSA-aligned microwave dual upconverter designed for demanding electronic warfare (EW) applications. The dual upconverter offers high dynamic range and performance operation from 6 – 18GHz with low phase noise and an internal local oscillator (LO). Optimized for future upgradeability, the purpose-built for SOSA alignment RFM3113 is packaged in a low-Swap 3U module and ideal for electronic attack, ELINT, and beamforming systems. The rugged build is suited for a variety of demanding environments with a broad spectrum of usability supporting greater performance in the field.

SOSA alignment means that this product is designed to meet the latest in open systems standards supporting commonality among products for customers. The design streamlines the deployment of the latest technology by increasing accessibility, efficiency, and maintaining interoperability and configurability. Although installation is simplified, security and ruggedness still meet Mercury’s high standards for secure, mission-critical technology.

Features:

  • Ultra-Wideband - Excellent phase noise - High Dynamic range
  • Built-in LO generation
  • External LOs capability for EW versatility
  • Two, fully independent upconverters
  • SOSA-aligned for greater interoperability
