ROCK 4 MC Small Mission Computer, BuiltSAFE™

Quickly deploy computing for advanced mission systems

Powerful computing that fits anywhere

A safe, powerful and compact mission computer featuring a safety-certifiable 11th Gen Intel® Core™ i7 processor, ROCK 4 MC enables system engineers and integrators to quickly scale computing infrastructure to speed artificial intelligence (AI) and autonomous mission applications without significant wait. The stackable, passively cooled and lightweight design is easy to install and doesn't require special cooling systems.

Easy to connect and customize

ROCK 4 MC's 4x4 video/sensor capture, processing and switching capabilities connect video to four displays and 2 TB of built-in SSD memory records raw camera and map data for mission debriefs and algorithm development. Experience rapid customization at a lower investment cost with a programmable video matrix, while secure boot and crypto key management capabilities safeguard critical data.

ASK A QUESTION


Dimensions


Download Now

Features Specifications Applications

Features

11th Gen Intel® Core™ i7 CPUs, built-in AI acceleration and an embedded GPU support AI and graphics/video capabilities
Connect and redirect video for up to four displays and perform 3G SDI and HD SDI overlay, fusion and composition
Easy-to-install stackable, passively cooled and 3.5 kg form factor speeds integration and doesn't require special cooling systems
2 TB on-board SSD to record raw camera and map data for mission debriefs and algorithm development
Reprogrammable video matrix and interfaces for faster customization and prototyping
DO-254 and DO-178 artifacts and support from Mercury’s expert design assurance team to meet multicore certification CAST-32A/A(M)C 20-193 objectives up to DAL C
Meet EUROCAE ED-202, ED-203 and ED-204 with secure boot and crypto key management
Ruggedized to DO-160G, MIL-STD-810 environmental standards to ensure operation during turbulent flights
Safety certification support
Maintenance and production support with Part 145 and Part 21G certified European facilities

REQUEST A QUOTE

Specifications

Processor

Intel® Core™ i7-1185GRE CPU
Quadcore/octothread @2.8 GHz
Vector (AVX-512) and AI accelerators

Memory

16 GB DDR4-3200 in-band ECC memory
Up to 2 TB on-board SSD

Networking

2.5 GbE port
1 GbE port
U SB 3.1

Video I/O

4x4 3G HD-SDI full-featured video matrix
ARINC 818 support on demand

Integrated Graphics Processing Unit

13th Gen Intel® Iris® Xe graphics
96 EUs
Video encode/decode H264/H265

Environmental and Test

DO-160G, MIL-STD-810

DOWNLOAD DATASHEET

Avionics I/O

(8) ARINC 429
(4) RS-422
(2) Gigabit Ethernet
(11) Discrete
(8) HD-SDI
(2) Audio
(1) GPS
(2) USB 2.0
(1) USB 3.1

Maintenance and Diagnostics

Integrated built-in-test (BIT) capability

BuiltSAFE® Proven Elements

DO-254 hardware
DO-178C graphics OpenGL 1.0, 2.0,
Vulkan
DO-178C GPU accelerated compute
DO-178C video encode/decode
Design and information assurance

Mechanical

Dimensions: 215 x 188 x 72 mm
Weight: <3.5 kg (7.7 lb)
Supply voltage: 28 VDC
30 W passive cooling
Up to 60 W with air flow

Board Support Packages (BSP)

Linux Distribution. Ubuntu, RedHat
Upon request: Greenhills, Deos, LynxOS, PikeOS, WindRiver

Applications

Platforms

Fixed-Wing Aircraft
Rotary Wing Aircraft
Ground Vehicles

Applications

Cartography and Navigation
Object Recognition and Tracking
Surveillance
Mission Management
Manned-Unmanned Teaming
Search and Rescue
Electronic Flightbag (EFB)
Onboard Entertainment
Situational Awareness
Video Processing and Switching
Displays

Quickly Expand Mission Capabilities

ROCK 4 small-form-factor mission computers integrate a powerful safety-certifiable Intel processor and video capabilities to enable customers to scale their computing infrastructure without significant wait or investment.
